General:

• Year: 2024
• Manufacturer: Polaris®
• Model Name: Ranger Crew XP 1000
• Trim Name: NorthStar Edition Ultimate
• Generic Type (Primary): Utility
• Engine Type: 4-Stroke Twin Cylinder DOHC
• Cylinders-Displacement (cc): 999cc
• Cooling: Liquid
• Engine Power: 82 HP
• Fuel System: Electronic Fuel Injection

Drivetrain:

• General:

  • Year: 2024
  • Manufacturer: Polaris®
  • Model Name: Ranger Crew XP 1000
  • Trim Name: NorthStar Edition Ultimate
  • Generic Type (Primary): Utility
  • Engine Type: 4-Stroke Twin Cylinder DOHC
  • Cylinders-Displacement (cc): 999cc
  • Cooling: Liquid
  • Engine Power: 82 HP
  • Fuel System: Electronic Fuel Injection

  Drivetrain:

  • Drive System: High Performance On-Demand True AWD/2WD/VersaTrac Turf Mode
  • Transmission: Automatic PVT H/L/N/R/P; Shaft

  Suspension:

  • Front Suspension: Dual A-Arm
  • Rear Suspension: Dual A-Arm, IRS
  • Front Travel (in./cm.): 10 in. (25.4 cm)
  • Rear Travel (in./cm.): 10 in. (25.4 cm)

  Brakes:

  • Front braking system: 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
  • Rear braking system: 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
  • Parking Brake: Park In-Transmission

  Wheels & Tires:

  • Wheels: 14 in. (35.6 cm) Aluminum
  • Front Tire: 29 x 9-14; Pro Armor X-Terrain | 8 Ply Rated
  • Rear Tire: 29 x 11-14; Pro Armor X-Terrain | 8 Ply Rated

  Dimensions

  • Bed Box Dimensions (LxWxH): 36.75 x 54.25 x 12.5 in (93.3 x 137.8 x 31.75 cm)
  • Ground Clearance: 14 in (35.6 cm)
  • Overall Vehicle Size (LxWxH): 152 x 65 x 79.5 in. (386 x 165 x 202 cm)
  • Seat Height: 33.25 in (84.5 cm)
  • Wheelbase: 113 in (287 cm)
  • Hitch/Type: Standard 2 in (5 cm) Receiver
  • Turning Radius: 17 ft (518 cm)

  Capacities

  • Bed Capacity: 1,000 lbs (453.6 kg)
  • Fuel Capacity: 11.5 gal (43.5 L)
  • Payload Capacity: 1,150 lb. (521.6 kg); California 1,150 lb. (521.6 kg)
  • Seating Capacity: 6
  • Rack capacity, front: 90 lb (40.8 kg)
  • Rack capacity, rear: 180 lb (81.6 kg)

  Weights

  • Estimated Dry Weight (lbs./kgs.): 2,387 lbs. (1,083 kg)
  • GVWR: 3,750 lb (1,700.9 kg)
  • Hitch Towing Rating: 2,500 lb (1,134 kg)

  Lights and Safety

  • Lighting: Dual LED Headlamps, 1250lm Low Beam, 2300lm High Beam, Dual LED Taillamps
  • Features: Polaris HD 4,500 Lb. Synthetic Rope Winch with Autostop and Wireless Remote, Premium Pro-Shield Cab, Doors with Power Windows, Tip-Out Glass Windshield with Wiper, Rear Glass Panel, Dome Light, Rearview Mirror, Heat, AC, Defrost, Premium Cut & Sew Seats with Contoured Seatbacks and Embroidered Polaris Branding, Premium Steering Wheel and Interior Accents, Polaris Pulse Electrical System with 6-Position Underhood Busbar and 6-Position Roof Busbar, Standard In-Dash SAE Charge Port, In Dash Speakers, Front & Rear Cameras, 7″ Glove Touch Display: Plow Mode, Group Ride, GPS Naivigation, Bluetooth, AM/FM Radio NFC Front Badge, NorthStar Badge, *Connectivity with Ride Command+. *Not available in International locations
  • Cargo System: Lock & Ride®
  • Instrumentation: Dual-sweep Analog Dials w/ 4″ LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, 2 DC Outlets, 1 USB Charge Port
